Easy Installation Nitrogen Air Separation Unit For Electonics Factory
Detail produk:
| Tempat asal: | CINA |
| Nama merek: | KERONG GAS |
| Sertifikasi: | ISO9001, CE, ASME |
| Nomor model: | Krn |
Syarat-syarat pembayaran & pengiriman:
| Kuantitas min Order: | 1 pc |
|---|---|
| Harga: | negotiable |
| Kemasan rincian: | Kotak kayu |
| Waktu pengiriman: | 8 minggu |
| Syarat-syarat pembayaran: | L/C, T/T, Western Union, Moneygram |
| Menyediakan kemampuan: | 1000 pcs per tahun |
|
Informasi Detail |
|||
| Nama: | Unit Pemisahan Udara Nitrogen | Kemurnian: | 90%~ 99.9999% |
|---|---|---|---|
| Titik embun: | -45 ℃ atau lebih | Bahan: | Baja tahan karat atau baja karbon |
| Kapasitas: | 5nm3/jam ~ 5500nm3/jam | Tekanan: | Bisa disesuaikan |
| Menyoroti: | PSA nitrogen generator for electronics,easy install nitrogen air separator,industrial nitrogen gas separation unit |
||
Deskripsi Produk
| Attribute | Value |
|---|---|
| Name | Nitrogen Air Separation Unit |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our Easy Installation Nitrogen Air Separation Unit is designed to provide a continuous, high-purity nitrogen supply (up to 99.99%) for electronics manufacturing and precision assembly processes. Utilizing advanced Pressure Swing Adsorption (PSA) or membrane separation technology, it separates nitrogen from compressed air efficiently, ensuring stable pressure and purity for sensitive electronic applications. The system features a compact, skid-mounted design for fast, hassle-free installation with minimal setup. Fully automatic and energy-efficient, it operates with low maintenance requirements, eliminating the need for bulk nitrogen deliveries. This generator ensures reliable, cost-effective nitrogen supply, supporting high-quality production in electronics factories.
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| KRN219 | 15 | 99 | 0.7 | 1200*600*1900 |
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
